1。威圖機柜在結構上可分為三個系列：帶五折型材機柜的ES機柜，帶九折型材機柜的PS機柜和帶16折型材機柜的TS機柜。 Rittal機柜的大特點是采用型材框架結構。 將機柜的框架焊接起來，然后用螺釘將頂板，底板，側板，門板和安裝板固定在框架上。這樣做的好處是該產品具有模塊化結構，易于使用；
1。 Rittal cabinet can be divided into three series in structure: ES cabinet with 50 fold profile cabinet, PS cabinet with 10 fold profile cabinet and TS cabinet with 16 fold profile cabinet. The biggest feature of Rittal cabinet is that it adopts profile frame structure. Firstly, weld the frame of the cabinet, and then fix the top plate, bottom plate, side plate, door plate and mounting plate on the frame with screws. The advantage of this is that the product has modular structure and is easy to use;
2。該產品是美麗的。威圖柜在工業(yè)產品的使用和外觀方面追求的理念。鈑金結構設計和配件的配套使用也非常合理和科學，形成了標準化的支撐設計；
2。 The product is beautiful. Rittal cabinet pursues the concept of perfection in the use and appearance of industrial products. The supporting use of sheet metal structure design and accessories is also very reasonable and scientific, forming a standardized support design;
3。內部縱向梁，柱，梁，人行道以及其自身的模制孔設計易于使用，使用戶安裝非常方便和方便。它還可以配備計算機托架，從而使維護非常方便；
3。 The design of internal longitudinal beams, columns, beams, sidewalks and their own molded holes is easy to use, making it very convenient and convenient for users to install. It can also be equipped with a computer bracket, which makes maintenance very convenient;
4。堅固，耐用，可靠。威圖柜的框架結構使結構穩(wěn)定。一個機柜的大負載為2000KG，因此您不必擔心安裝任何笨重的組件；
4。 Strong, durable, safe and reliable. The frame structure of Rittal cabinet makes the structure stable. The maximum load of a cabinet is 2000kg, so you don't have to worry about installing any heavy components;
5。同時，仿制的Rittal機柜的材料是碳鋼和不銹鋼。門板的默認材料厚度為2.0毫米，安裝板的默認厚度為2.5毫米，柜體的默認厚度為1.5毫米；
5。 At the same time, the materials of the imitation Rittal cabinet are carbon steel and stainless steel. The default material thickness of the door panel is 2.0mm, the default thickness of the mounting plate is 2.5mm, and the default thickness of the cabinet body is 1.5mm;
6。碳鋼的默認表面處理是塑料噴涂。噴涂前，顏色為RAL7035。不銹鋼的默認表面處理是拉絲。
6。 The default surface treatment for carbon steel is plastic spraying. Before spraying, the color is ral7035. The default surface treatment for stainless steel is wire drawing.
The above wonderful content comes from: imitation Rittal cabinet. For more wonderful content, please click to enter our website: http://www.cnshanqi.com , we will have more content for you later
